IMPORTANT NOTE ON LR/ROVER MANUALS 2026 January

Note: This roughly.., It cannot be made rigorous

1. By the 1970s, local dealers in the USA altered the Plus 8s fueling systems upon arrival (saving in a few cases, the Cantab cars in the late 1980s). Most Plus 8s were convertd to propane using carburetors. Many owners then converted them to petrol again, using Holley 390s and Carter/Edelbrock/Weber 500s

2. By the 1990s, the Morgan Motor Company used different blocks and fueling systems for Plus 8s destined to different places.

        a. in the UK/Europe, the Plus 8s used either Stromberg carburettors from 1984 to 1986 or L-Jetronic fueling and then only L-Jetronic from 1986 to 1990.
        b. in the UK Europe, the Plus 8s used the Hitachi Hotwire system from 1990 to early 2000.
        c. in the UK Europe, the Plus 8s used GEMS from 2000 to 2004

        d. Overseas (the USA and Downunder primarily) the Plus 8s used a bespoke variant of GEMS from 1998 to 2000.
        e. Overseas (the USA and Downunder primarily)  the PLus 8s then used the stock variant from 2000-2004.

This does not speak to the structural & safety changes to Overseas cars.

WATCHPOINT: As a consequence of the information above, Plus 8s are very different. These variants drastically change the performance of the cars and how to deal with them. Sadly, even dealers are not very savvy with variants sent to another continent!  Serious advice errors occur daily on forums where owners in one country give to advice to owners on another! I can help.

3.9/4.0/4.6 Differences (see below for Buick/3.5/4.0/4.6 differences)
by Lorne Goldman

What are the differences between a 3.5, a 3.9 or 4.0 or 4.6 litre engine? Both have a bore of 94.0 mm and a stroke of 71.1 mm.
There seems to be no difference in capacity at all!

The differences are:

When the 4.0 and 4.6 were introduced, a completely new block of the motor was made. The changes included:

1) Extra ribbing on the motor to strengthen it.

2) Machined steps into the bore that would prevent the liners from ever moving which didn't work

3) Larger diameter crank.

4) Larger main bearings.

5) 4 bolts holding each main bearing in place

6) The camshaft was held in place by a retaining plate.

7) oil pumps were driven directly off the crank. Had 25% more volume capacity and can maintain 50 psi.

8) The heads only had 10 bolts instead of 14.

9) The heads were skimmed to allow thicker composite head gaskets to be used rather than the old metal ones.

10) TTY head bolts were used.

11) The 3.9 block has provisions like the 4.0/4.6 litre for the very welcome cross-bolts but they have not been drilled This can be done as a preface to more power.

12) The 3.9, 4.0 and the 4.6 has the smaller main journals than the 3.5.

13) The 4.0/4.6 crank has a longer nose.

14) The 3.9 has the concentric oil pump but coupled with standard distributor. The 4.0/4.6s has a distributorless system and thus no hole for a distributor. However, the Morgan 4.6s sold until 2000 has a 3.9 top end, with a distributor, the earlier fuelling system and a 3.9 fuel map.

15) The 4.0/4.6s use longer rods, lighter and shorter pistons.

16) The 3.9 had the 14CUX 'hotwire' fuel injection. The 4.0 has the Lucas 'GEMS' engine management system (latest see Bosch 5.2.1 Motronic)

17) Because of the way the fueling and ignition is set up,  the standard LR 4.0 has knock sensors and the 3.9 does not. However, the MMC system removes the knock sensors, forcing the ignition to "fly blind".

18) the 4.0 puts out 186.4 bhp and the 3.9 puts out 190.3 bhp. Because of its inadequate fuelling, the Morgan 4.6s (overseas 4.6 have an unknown output).

If you know of other differences please send them in to keep the page current.

BUICK 215/ROVER 3.5 AND THE LAND ROVER 3.9, 4.2, 4.0 & 4.6 ENGINE DIFFERENCES


1. The 4.0/4.6 crankshafts are also longer to drive the new oil pump
2. A new connecting rod design was used for the 4.0/4.6. They are made from forged steel and now have balance pads on both the small and big ends; the screw-in bolts retaining the caps are of a more robust design and are manufactured to extremely fine tolerances. The 4.0-litre engine uses a rod 1 55.2 mm in length, and the 4.6-litre is 149.7 mm with a55.5 mm big end bearing diameter, the older version having a 50.8 mm big end bearing. The increase in length was done to reduce the angularity of the rods in the engine, thus reducing vibration. The small end size has been increased from 22.2 mm to 24mm.
3. The pistons are also new and are a common design between the 4.0 and 4.6-litre engines. The capacity of the bowl in the piston crown varies slightly between the two engines (4.0-litre, 13.23 ccl4. 6-litrr, 22.29 cc) to determine the compression ratio. To maintain equality of material thickness on the piston crown they are different castings. Having said that, the compression ratios are the same for both engines --9.35:1 although lower 8.2:1 compression pistons are available. The original 3.5/3.9-litre engines have pistons 80.9 mm long overall, with a compression height (or crown height) of 49.5 mm, while the longer stroke 4.2-litre engine uses a piston 72.85 mm long with a compression height of 45 mm.
4. The 4.0/4.6-litre engines have a shorter piston of 66.6 mm, with a compression height of only 35.9 mm.
5. The 4.04.6 gudgeon (or wrist) pin diameters have been increased and they also have a gudgeon pin offset. The 4.2-litre engine was the first  production Rover V8 to use this feature, but on the 4.0/4 6 litre engines it has been increased from the 0.55 mm of the 4.2-litre to 0.60 mm. The reason for this offset is to produce a slight side loading on the piston at TDC, thus eliminating piston slap all part of the infinite attention to design detail by the Rover engineers in their quest for refinement.
6. The 4.0/4.6 cylinder blocks have been made significantly stronger by the addition of stiffening ribs (taken from the Sd1 Vitesse) in key areas (along the block sides near the main bearing webs, for instance) and, more importantly, both 4.0 and 4.6 litre blocks now have cross-bolted main bearing caps. Of course Rover have produced cross-bolted blocks before, but they were special items and expensive, one of the reasons being that the main caps had to be individually ground to match the block. The new blocks have this feature productionised, although they are now a press fit in the block. The cap material has also been upgraded from grey to SG iron.
7. The interior profile of the 4.0/4.6 block has been altered to make room for the redesigned crankshaft with its bigger bearings and bigger counterweights. The cylinder liners are 5 mm shorter and the oil pick-up from the sump no longer fits into the block casting, from where the oil made its way to the pump via a drilled gallery; the pick-up on the new engine.
8. There are two new crankshafts, one of 71 mm stroke for the 4.0-litre and one of 82 mm for the 4.6-litre version.
9. The main bearing size has gone up from 58.4 mm to 63.5 mm and the counterweights are larger, although of the same number as before.  These new crankshafts will not fit into older engines because there is insufficient room for the bigger counterweight to rotate inside the block. The stroke of the 4.0-litre crank is identical to the old 3.9-litre, as is the cylinder bore of 94 mm, so the capacity of these two engines is the same.


                                     COMPARISON BETWEEN BUICK/ROVER/LR ENGINES
Engine Bore x Stroke Capacity
Buick 215/Rover 3.5 88.9mm x 71mm (3.5" x 2.8") 3500cc
Rover 3.9/Rover Crossbolted 4.0 94mm x 71mm (3.7" x 2.8") 3950cc
Rover 4.2 94mm x 77mm (3.7" x 3.0") 4278cc
Leyland Australia P76 4.4 88.9mm x 88.9mm (3.5" x 3.5") 4416cc
Rover Crossbolted 4.6 94mm x 82mm (3.7" x 3.2") 4554cc


Displacement  Bore Stroke Main Brg Rod Big End Brg Wrist Pin Rod C/L to C/L
 215CI BOP 3.50 2.8000 2.3000 2.0 .8750 5.660
 300CI Buick 3.75 3.3600 2.5000 2.0 .9390 5.960
 3.5L Rover
3.50
2.8000
2.2993
2.0
.8750
5.660
 3.9L Rover
3.70
.8000
2.2993
2.0
.8750
5.660
 4.2L Rover
3.70
3.0000
2.2993
2.0
.8750
5.660
 4.4L P76
3.50
3.5000
2.5495
2.0
.8750
6.250
 4.0L Rover
3.70
2.8000
2.500
2.185
.9449
6.111
 4.6L Rover
3.70
3.2283
2.500
2.185
.9449
5.897

A NAS 4.0 Anomoly (1998-2002 models)

Experience seems to show that, when in doubt, the US Plus 8s (4.0 1998-2002) NAS SAGEM fueling system ECU (computer) will revert to a default setting. Like most default setting, the car will be protected for a presumably a short period by running very rich. There will be a smell from the cats of rotten eggs and the car will react poorly with a bad idle and sluggish performance.

Many things can produce this state...a prolonged non-use of the car..a lack of power to the ECU or overfilling the petrol tank.

In such a case with these symptoms, the ECU must be reprogrammed to run properly again. TRhis is a simple matter if you know the setting and you have access to a LR dealer or specialsit with wither TESTBOOK (the LR diagnostic and prgramming serrvice unit) or Rovercom, an aftermarket item that does the same thing.

Unlike other LR units, the Morgan is reprogrammable and you will have to tell the experienced mechanic with the diagnostic unit mentioned to use the disk for "1997 Range Rover GEMS 4.0L UK Manual Type 1 ID 9660". Once re-programmed to that specification, the car should run perfectly again.

The Story of the Morgan 4.6s February 2, 2018

I was just contacted by an UK mogger I like very much. Puzzled, he has asked a question that I haven't dealt with in years. The Morgan cogniescenti has largely withdrawn from view in the last decade and much has been forgotten.  People should know as much as is possible about their beloved cars.
His question arose from confusion on Morgan blocks numbers and the Morgan 4.6s.This is very understandable as for a period (1997-2000) Morgan simultaneously produced Plus 8s with two different generations of original LR V8 blocks/heads and fueling systems (the then already obsolete 3.9s with Hotwire fueling for the UK and the more advanced 4.0 blocks with GEMS This ended in 2000 when Morgan went to GEMS for all Plus 8s fueling for  overseas distribution).

There were many reasons for this given by the company, few of them credible. For example, at the time the UK market was told that the later GEMS system or later the Land Rover Bosch Motronic system "would not fit under the Morgan bonnet!", which didn't make sense considering the hundreds of GEMS Plus 8s supplied overseas. The simple truth, I suspect, was that GEMS and MOTRONIC were more expensive for Morgan than the older Hitachi Hotwire systems and British law allowed the local sale of 3.9s until 2000. That being said, engine fiddlers like me and top tuners prefer the Hotwire for a number of reasons. It certainly allows for easier upgrades and owner intervention than the later GEMS!  (Though no Morgan EFI system is as easy to take care of, adapt and part source than the L-Jetronics (flappers).

But another problem appeared for Morgan.

By 1996, news had come of the production of the anticipated 4.6 version of the venerable Buick/ Rover/LR blocks. Every fan of Land Rover and the other marques using the block were excited. The 4.2, never used in a Factory Plus 8,  had largely been a disappointment and the 4.0 and 4.6 went much further, with cross-bolting and other features. And this was before the infamous plague of Land Rover V8 block cracking and slipped liners had begun in earnest. (With the low Morgan weight, this was not a problem for us.)

So Morgan had a goodly number of 4.6s on order in anticipation, at a premium price. Even Peter Morgan put his order in for one to be his personal car, AB16! It was also to have the newer "wide body" with the new Superform wings (much wider than anything contemplated in prior Plus 8 history). Problem is, everyone wanted the 4.6 in their truck when it appeared and Land Rover couldn't deliver to Morgan. I believe (unconfirmed) that the problem was GEMS fueling system, not the blocks.

But Morgan came up with a solution to save those sales. They went to John Eales. John should need no introduction to Plus 8ers. He deals in race preparation and supply of LR engines. Morgan asked Eales to supply new 4.6 blocks, modified and fit with 3.9 Hotwire top ends and fueling systems. (With a bit of modification parts, all blocks from 1976 can be retro-fit with earlier or later systems.) So now they had bigger 4.6 blocks fit with earlier fueling systems made for 3.9s!

Here is the Morgan announcement that was sent to me. It is confusing and inaccurate, indicating the state of the company management technological understanding at the time. I ask the reader to overlook these errors.

Morgan Motor Company: June 1997 Dealer Notice:

"As it has not been possible to obtain the current Range Rover 4.6 litre engine, due to supply problems with Rover and because of the modifications required for installation, we have arranged for a special engine to be prepared.

This uses the current 3.9 litre engine, but built using the standard 4.6 litre block. This involves stripping a new engine, removing the block, specially modifying a 4.6 litre block to accept the front cover, and rebuilding the engine.

This produces a special unit using largely standard Rover parts. The distributor set-up is largely the same as 3.9, as is the camshaft and ECU. The block is cross bolted for strength. The crank, pistons and block are standard Range Rover 4.6".

Of course, logic dictates that  one cannot get much more horsepower by providing the same amount of fuel to a larger bore engine, EVERYTHING ELSE being equal. In fact, the combination MUST run lean and hot as you are feeding a larger combustion chamber with the same amount of fuel! And the later 3.9 Hotwires already run too lean as stock! In fact, if you examine the figures given by Morgan, they show a mere 1.8% increase in bhp over the 3.9L block of the day albeit the 4.6 had a 2500 GBP price premium which sadly produce bragging rights only in its Morgan version. More than twenty years ago, John Eales told me he tried hard to get Morgan to allow him to create or provide them with a more appropriate chip/eprom (aka fuel map) which would release the extra power eveyone assumed would result from the bigger block and keep the motor problem free. Land Rover, with merely their stock 4.6 fueling and a truck 4x4 cam produces 30 more bhp (almost 20%!) with the same engine. However, a more appropriate chip was refused by Morgan, either for reasons of economy or perhaps worries about a need to re-test the engine for emissions. In any event, it was never done. Sadly, this also came at time when the fueling was already as lean as the fuel map of the 3.9 could be made to provide. This was why LR was transitioning to the GEMS and then MOTRONICS at the time. Additionally, owners would soon compound the lean fuel mixture with K&N air filters and performance exhaust systems. The lean mixture is unhealthy for the engine.

WATCHPOINT:  The Morgan 4.6 fuel map:  I have always advised the Hotwire MMC 4.6 owners who contact me to fit a Tornado chip and they are universally thrilled, not simply with the added power and torque but with the new experience of running cool. Sadly, by the time they get to me, they have all often spent a fortune trying to improve the cooling systems. I am am a fan (pun!) of better cooling for Plus 8 but trying to fix a fueling issue with better cooling is analogous to using a huge bandaid in hope of curing double pneumonia.  As always, I have NO connection with Tornado systems or any supplier mentioned.

WATCHPOINT: 4.6 Potential Power  By way of example only, I note to you that two of my three Morgan Plus 8s have sported new 4.6s which I have adapted to my original EFI (Bosch L-Jetronic) system. One was created with a goal of maximum road-reliable power for North America and the other with a desire to have a thoroughly reliable tourer for Eueopean backroads and the uncertainty of their fuel quality.  I have rolling road dyno'ed the North American version four times and the European car once. I use rolling dynometers as a the best tuning device..and NOT for ego boosting. To my mind it is the ONLY place to test the veracity of add-ons. The North American car was run on 94+ octane (aka 100 octane in the UK), easily findable in Canada. hThe L-Jetronic (Flapper) system is the least sophisticated EFI system, and the compensation for that is the fact that it is the most user friendly, re-tunable in minutes.

The dyno tests show a maximum bhp and torque at 307 bhp and over 300 for torque. In fact, unless I am racing, I detune the car for greater reliability to 292 bhp (without much effect of torque. However, this is almost 50% greater performance than the MMC version of the 4.6!! The other version of the 4.6 I  used in Europe used a 4.6 with a lower compression. No effect on torque but a BIG loss in bhp from the CDN car. (The trade-off made it immune to lousy petrol found in Continental or backwoods Tennessee rural filling stations.) It dynoed at 254 bhp (using the rolling road dyno in Cheltenham in the Cotswolds. More than 25% more power than the MMC's 4.6s that uses a higher compression engine!

Additionally, these engines run healthier and will last much longer with far fewer problems. The Tornado fuel map will NOT achieve the first figures. But they will make it to the second set produced by my UK car. Sadly, Morgan forums are now (2018) nowhere what they once were and much of the hard-earned lore is no longer common knowledge. One must had to search to find it again.

The MMC 4.6s (aside from some overseas 4.6 GEMS units) overheat. Many owners, internet savvy and former eMog adherents have addressed the issue. Owners adopt the new they-all-do-that attitude of the current Morgan community. :(

I have a number of Buick, Rover and Land Rover V8s in spares. I enjoy them all, as they all give the Plus 8 a different personality. But after more tha 225,000 miles, two continents and more than 25 years, I unabashedly admit to loving the 4.6 variants more than all others in Plus 8 history. They can be made infinitely owner friendly, with the best Morgan touring engine ever as they are super flexible. Roadside mechanics are familar with them on all continents. The mistakes Morgan made with their UK 4.6s are tragic. However, they are easy to sort. Sadly, the current community is no longer as mechanically adept as it was and who can recognize inadequate fueling without an exhaust analysis and a basis for comparison? Owners are unaware of the issues and all good drivers unconciously adapt their driving to what they got. The increased capacity indicates that the 4.6 MUST be more powerful so everyone assumes it. Yet it is merely another problem Morgan waiting for the right owner to ask the right questions and act upon the right answers. It would be a shock for these owners to see what that engine can really do..assuming it is undamaged after a decade of incorrect fueling.

These cars are easy enough to recognize. UK 4.6s, and their block numbers do not indicate a made-for-Morgan origin. John (Eales) would have their source and numbers but it would be unkind to place him in a conflict that is not of his making. He is a good guy.

MATCHING SENDORS TO GAUGES ELECTRONICALLY
by Lorne Goldman and Tim Waller
1. Matching Sendors to Gauges Electronically 1 (Spyda)

2. Matching Sendors to Gauges Electronically 2 (Speedway)

3. Matching Sendors to Gauges Electronically 3 (Tanks MeterMatch)

WATCHPOINT: An astute Morgan mate of mine pointed out that these devices are made for cars that have instruments that function with ohm signal senders rather than the older gauges on very early cars that function with a varying voltage signal. Confirm what type of gauge you have if you have a pre-1970's Morgan


CRACKING BLOCKS AND SLIPPED LINERS

The 3.9 and 4.2 were basically 3.5's bored out (stroked also for the 4.2)

When the 4.0 and 4.6 were introduced, a completely new block of the motor was made. The changes included:

1)  Extra ribbing on the motor to strengthen it.
2)  Machined steps into the bore that would prevent the liners from ever moving.
3)  Larger diameter crank.
4)  Larger main bearings.
5)  4 bolts holding each main bearing in place rather than the previous 2.
6)  The camshaft was held in place by a retaining plate.
7)  Oil pumps were driven directly off the crank. Had 25% more volume capacity and can maintain 50 psi.
8)  The heads only had 10 bolts instead of 14.
9)  The heads were thinner to allow composite gaskets to be used rather than the old metal ones.
10) TTY head bolts were used.

The 3.9s, the 4.2s, the 4,0s and the 4,6s allsuffered a bad reputation for cracked blocks and slipped liners getting progressively worse. And from the 3.9s on, the aluminium casting between the sleeves and the coolant areas were made thinner due to the bigger bore size. But this was only part of the issue. Due to emission requirements, Land Rover increased the operating temperature of the motor through higher temp thermostats. This increased the stress on these coolant areas. Ultimately causing issues with blocks and liners. This thermostat issue was fixed during the period of the Disco 2 with the early models having the high temp version, then they introduced an interim thermostat that was a bit cooler, and then finally the lower temp one that put the engine temps back to pre-emmission motors. The low quality tolerance with the blocks was not great and this led to motors with very thin walls being put into cars.

Finally, there was not a lot physically stopping liners from moving if the heat expansion of the block reduced the tolerance fit of the sleeves.

Due to the casting method used to make the blocks, the exact thickness of the walls around the sleeve is difficult maintain.

After 4 years in production, in 1993 Land Rover recognised the issue with wall thickness and started ultrasonic testing all blocks to check the wall thickness. After the initial test results were compiled, the block mould was changed to reduce the amount of variance in wall thicknesses.

Blocks that had a wall thickness less 2.2mm were melted and recast.

Prior to this testing it was found that motors were being put into cars that had wall thicknesses as low as 1.2mm. Again leading to the poor reputation of the 3.9 and on V8's.

The 4.6 motors were first used Range Rover P38. Unfortunately there was a new design problem with the top radiator hose that caused the hose to break and dump all the coolant. The radiator was also too small, the thermostat temp was too high, and the design of the top radiator hose left an air pocket. This of course meant overheating the motor. Do this enough times and you will have issues with head gaskets and the block cracking behind the liners. These design issues, unrelated to the actual motor, also gave the early 4.6 motor a bad rep.

In 1997 they actually started to grade the blocks. Blocks with a minimum wall thickness of 2.8mm were used for the 4.6 motors, the ones 2.2mm to 2.7mm were used for the 4.0 motors.

On original motors you can tell the grading of the block by a dob of paint in the valley of the block. Unfortunately this paint will disappear if the motor has been rebuilt and therefore you will not know the grade of the block in these circumstances.

The message from all this is that the motor is not the same one designed by Buick in the 50's, it has been changed many times over the years to try and fix any known issues with the motor.

So just because it was an issue with the 3.9 or 4.2 does not mean that it is an issue with the 4.0 and 4.6.
Just because it was an issue for the 4.6 powered Range Rover P38's, it does not mean that it will be an issue for your Discovery or later Range Rovers.
If you have a vehicle that was originally fitted with the hotter thermostat, change the thermostat to an 82C version.

FROM FORUMS

Rover rode the Buick V-8 horse into the dust, trying year after year to squeeze just one more year out of it while the latest in a series of owners gave up and tried to off the company to someone else. These problems were greatly amplified by the fact that owners tried maintaining them like Toyotas. The aftermarket and enthusiast owners figured out how to keep them alive with various fixes, like liners, head studs, etc.

After 4 years in production, in 1993 Land Rover recognised the issue with wall thickness and started Ultrasonic testing all blocks to check the wall thickness.

It took them four years of warranty claims and replacing customer engines to buy the guy at the foundry a $300 tester?!!!!!

And then this gem---  Again leading to the poor reputation of the 3.9 V8's.

What about the poor reputation of the 4.6? Head bolt failures, blown head gaskets, exploding oil pumps, weak cooling system components... enough to keep a forum like this filled with a non-stop flow of new members.

Speaking, as I said before, globally, your most recent advice to the member having coolant leakage problems, where you suggested he replace his water pump as it was likely there was water leaking from the back and into the crankcase... That sorta tells me you'rte really not too familiar with the product. A water pump is pretty basic and you are making repair recommendations and dispensing information that doesn't come close to matching how the water pump is mounted to the engine.

 In this thread, and I'll try to be more succinct... it feels like a "look at how much I know and what an insider I am" thread. Unfortunately, most of what you posted is poached from other web sources. And, as I asserted before, what you were posting about very "inside baseball" details about minutiae regarding things happening on a production line or casting plant- either you would have had to been working at Rover or had a close relationship with someone that did and, for some reason, felt the need to share pedestrian details about his day-to-day. In short it sounds like bullshi(r)t. Even if it wasn't (unlikely) none of it was any more informative or useful to people with real-world issues. But, on behalf of the rest of the members here, thanks for sharing your intellectual masturbation with the rest of us.

In closing, your last comment is a true gut-buster. Land Rover was not striving for perfection via continued improvement in their product lineup. They had a product hopelessly out-of-date and uncompetitive in the marketplace. They had no money for upgrades. They were being groomed to be offed to the next owner. and before you assail me as a Rover-hater, remember- I own several. I'm here.
